TFT Handline Automatic Nozzle w/Grip 38mm NPSH

https://www.wfrfire.com/web/image/product.template/8967/image_1920?unique=2eb07a3

  • Product Option
  • Product Pressure

This combination does not exist.

Nozzles/Monitors
Product Option: With Pistol Grip & Shut Off

Features

Automatic 100 psi (7 bar) pressure control with a flow capacity of 95-300 gpm (360-1150 l/min). Includes flush without shutting down, patented slide-type valve for turbulence-free flow control, six detent flow positions, molded rubber teeth for full-fill "power fog", and "Gasket Grabber" inlet screen. Pistol grip is mounted below the valve. Lightweight hard coat anodized aluminum materials for maximum resistance to corrosion and wear.1.5" NH (38mm) rocker lug full-time swivel coupling is standard.

Specifications

 Pistol GripYes
 Valve DesignStainless Slide Valve
 Flow Rate95-300gpm (360-1150 l/min)
 Inlet Coupling StyleRocker
 Body Size1.5" (38 mm)
 Inlet Coupling SwivelFull Time Swivel
 StyleOne Piece with Valve
 Pressure ModeSingle
 TypeAutomatic
 Fog TeethFixed
 Operating Pressure100 psi (7 bar)
 Remote ControlNo
 Weight7
 Bumper MaterialRubber - bonded
 Inlet Connection TypeNH Female
