Perfect for ventilating in confined spaces. Extremely light weight and compact.
NEGATIVE PRESSURE VENTILATION This Smoke Ejector is designed to perform effective and efficient negative pressure ventilation, or NPV. While positive pressure ventilation (PPV) blows air into a structure, negative pressure sucks air out. This can be useful in confined space situations and/or when ventilated air must be controlled to a greater extent.
AIRFLEX COMPOSITION IMPELLER Uniquely designed impellers deliver maximum air volume (CFM), velocity and pressure. Every size and type of fan features a blade designed specifically for it to deliver the greatest performance possible. Composite blades are much safer than traditional metal blades as they are designed to disintegrate upon impact of any foreign objects. Metal blades may fragment when integrity is compromised, potentially causing severe injury.
COMPACT SIZE AND WEIGHT
Lightest weight and most compact ventilator available for extremely
convenient use and transport. Its reduced dimensions make it perfect for
compartments with limited space and confined space ventilation. At
under 50 lbs., lifting and carrying this unit is a breeze and ideal for
departments which often carry their ventilator over long distances or up
and down stairwells.
SINGLE SPEED MOTOR The EBS-16 comes standard with a single speed electric motor with an output of 0.3 HP. This specific motor is matched perfectly with the fan blade’s size and pitch to produce the most effective air movement possible.
HANG SUSPEND THE EBS-16
One of the key advantages to the EBS-16’s light weight and compact
design is its ability to be quickly suspended in nearly any door or
window way. Want to ventilate a difficult to access and crowded interior
space through a window? No problem. NOTE: For safety, we encourage the
use of the Tempest Door Bar Holder (300-141) and Hanging Bracket Set (300-142)
to properly hang the Tempest EBS-16.
LIGHTWEIGHT
At 47 lbs., the Tempest EBS-16 is one of the more light weight
ventilation units available. Its reduced dimensions and frame design
allow users to easily carry it to and from the work site.
FORMED & WELDED ROLL-CAGE FRAME
Not an ounce of Tempest’s well-known reliability and durability that
comes standard on every fan was sacrificed to meet this unit’s small
stature and light weight. The frame is made up of entirely steel; all
molded, formed and welded into a sturdy roll-cage design. Like every
Tempest, it’s built to last on the job site.
SAFETY GRILLE
Front and rear safety grilles feature a continuous spun wire body with
four tie point bars. Meets strict European CE Safety Standards.
PRODUCT CHARACTERISTICS
While they’re not as effective as positive pressure ventilators, Smoke Ejectors are still the go to for many departments around the world for their compact size/weight, simplicity and affordability. Perfect for ventilating in confined spaces. Extremely light weight and compact for convenient lifting/carrying and storage/transport.
SPECIFICATIONS
- 16" Diameter blade
assembly made up of 6, AirFlex Fiberglass Reinforced Polyamide Blades
- 0.3 HP Motor
- 3,200 CFM
- Continuous circular wound shroud, zinc-plated steel with 4 tie points for additional safety
- Meets UL & European CE Safety Standards
- Formed and welded sheet metal frame construction with powder-coat finish
- 18.75"w x 14.25"d x 19.5"h (47.6cm x 36cm x 49.5cm)
- Weight:
47 lbs. (21.4kg)
