NEVER BLOCK POINT OF EGRESS
Only prevents air movement through the opening, not personnel. Deploys in any doorway or window opening without obstructing the point of egress unlike closing the door or window. Frees up personnel from having to manage a closed doorway.
CONTROL THE FLOW PATH
Allows a firefighter to easily open and close flow paths. Puts fire movement/growth control in the department's hands. Application based on recent research conducted by UL FSRI on interior flow paths.
AMPLIFY PPV/PPA - INCREASE PRESSURE
Effectively reduce doorway size allowing closer fan placement while maintaining necessary air seal. Fan closer to the ventilation point increase internal pressures and resulting ventilation rates from 50 to 100%.
CONTROL SMOKE MOVEMENT & DAMAGE
Create a temporary blockade, almost entirely eliminating smoke spread and movement between rooms. Keeps escape routes such as stairwells free from blinding and suffocating smoke. Significantly helps to prevent unnecessary smoke risk. damage, saving property.
SPECIFICATIONS
Fabric is Silicone impregnated Fiberglass. Heat resistant up to 1100°F/600°C (use in temperatures exceeding 500°F/260°C will slowly degrade the fabrics protective coating. This is normal and does not immediately affect the products function. The fabric is designed to be replaced easily if/when its protective coating has been compromised beyond use).
Frame is 1.25" Aluminum Square Tubing with Quick Ratchet/Screw Width Adjustment.
| Size | Dimensions Collapsed (WxDXH) | Span Width | Height |
| XL | 36" x 2" x 21.5" | 36" to 59" (adjustable) | 75" |
